Camera
Image Sensor 1/1.8" progressive scan CMOS
Min. Illumination Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2，AGC ON), 0 Lux with IR
Shutter Speed 1/1 s to 1/30,000 s
Slow Shutter Yes
Day ＆ Night IR cut filter
Zoom 42x optical, 16x digital
Max. Resolution 2560 × 1440
Lens
Focus Auto, semi-auto, manual, rapid focus
Focal Length 6.0 mm to 252 mm
Zoom Speed Approx. 4.5 s
FOV
Horizontal field of view: 56.6° to 1.7° (wide-tele),
Vertical field of view: 33.7° to 0.9° (wide-tele),
Diagonal field of view: 63.4° to 1.9° (wide-tele)
Aperture Max. F1.2
Illuminator
Supplement Light Type IR
Supplement Light Range up to 400 m
Smart Supplement Light Yes
PTZ
Movement Range (Pan) 360°，Smart Pan-Tilt Correction
Movement Range (Tilt) -20° to 90° (auto flip)，Smart Pan-Tilt Correction
Pan Speed Pan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
Tilt Speed Tilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
Proportional Pan Yes
Presets 300
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans, record time over 10 minutes for each scan
Power-off Memory Yes
Park Action
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,
panorama scan
3D Positioning Yes
PTZ Status Display Yes
Preset Freezing Yes
Scheduled Task
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,
panorama scan, dome reboot, dome adjust, aux output
Video
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16384 Kbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 8 fixed regions for each stream
