Camera
Image Sensor Two sensors, 1/1.8" Progressive Scan CMOS
Max. Resolution 2560 × 1440
Min. Illumination Color: 0.0004 Lux @ (F1.6, AGC ON), B/W: 0.0001 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed 1/1 s to 1/30000 s
Zoom 35 × optical, 16 × digital
Slow Shutter Yes
BLC Yes
3D DNR Yes
Lens
Focal Length 5.9 to 206.5 mm
FOV
Horizontal field of view: 60.2° to 2.24°, vertical field of view: 36° to 1.26°, diagonal field
of view: 68° to 2.56°
Focus Auto, semi-auto, manual
Aperture Max. F1.6
Zoom Speed Approx. 4.3 s
Illuminator
Supplement Light Type Hybrid
Supplement Light Range IR distance: up to 300 m
Smart Supplement Light Yes
PTZ
Movement Range (Pan) 360° endless
Movement Range (Tilt) -20° to 90°,auto flip
Pan Speed Pan speed: configurable from 0.1° to 210°/s, preset speed: 280°/s
Tilt Speed Tilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
Proportional Pan Yes
Presets 300
Preset Freezing Yes
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans, record time over 10 minutes for each scan
Park Action
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,
panorama scan
3D Positioning Yes
PTZ Status Display Yes
Scheduled Task
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, dome
reboot, dome adjust, aux output, panorama scan
Power-off Memory Yes
Video
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16 Mbps
H.264 Type Baseline profile, Main profile, High profile
H.265 Type Main profile
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 8 fixed regions for each stream
