Camera
Image Sensor 1/2.8" progressive scan CMOS
Max. Resolution 2560 × 1440
Min. Illumination color: 0.05Lux @ (F1.6，AGC ON)||B/W: 0.01Lux @(F1.6，AGC ON)||0 Lux with IR
Shutter Speed 1 s~1/30,000 s
Day & Night IR cut filter
Zoom 25 × optical,16 × digital
Slow Shutter yes
Lens
Focal Length 4.8 mm~120 mm
FOV
Horizontal field of view: 55° to 2.4° (wide-tele),
Vertical field of view: 33° to 1.4° (wide-tele),
Diagonal field of view: 61.5° to 2.8° (wide-tele)
Focus semi-auto||manual||auto
Aperture F1.6
Zoom Speed approx.3.6s
Illuminator
Supplement Light Type IR
Supplement Light Range IR distance: up to 150 m
PTZ
Movement Range (Pan) 360°
Movement Range (Tilt) -15° to 90° (auto flip)
Pan Speed pan speed: configurable from 0.1° to 120°/s; preset speed: 120°/s
Tilt Speed tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
Proportional Pan yes
Presets 300
Preset Freezing yes
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans
Park Action
preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame
scan||panorama scan
3D Positioning yes
PTZ Status Display yes
Scheduled Task
preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame
scan||panorama scan||dome reboot||dome adjust||aux output
Power-off Memory yes
Video
Main Stream
50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720）
60 Hz：30 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720）
Sub-Stream
50 Hz：25 fps（704 × 576，640 × 480，352 × 288）
60 Hz：30 fps（704 × 480，640 × 480，352 × 240）
Third Stream
50 Hz：25 fps（1920 × 1080，1280 × 960，1280 × 720，704 × 576，640 × 480，352 ×
288）
60 Hz：30 fps（1920 × 1080，1280 × 960，1280 × 720，704 × 480，640 × 480，352 ×
240）
Video Compression H.265||H.264||MJPEG
H.264 Type Baseline Profile||Main Profile||High Profile
H.265 Type Main Profile
Scalable Video Coding (SVC) yes
Region of Interest (ROI) fixed region
