Dimensions
159.7 x 156.7 x 33.8 mm
(6.3 x 6.2 x 1.3")
WiFi Standard
WiFi 6E
Spatial Streams
10
Coverage Area
115 m² (1,250 ft²)
Max. Client Count
600+
Uplink
2.5 GbE
Mounting
Wall
(Mount Included)
Power Method
PoE+
PoE++ (Required for PoE output)
Performance
MIMO
6 GHz
4 x 4 (DL/UL MU-MIMO)
5 GHz
4 x 4 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
6 GHz
4.8 Gbps (BW160)
5 GHz
4.8 Gbps (BW160)
2.4 GHz
573.5 Mbps (BW40)
Antenna Gain
6 GHz
5.8 dBi
5 GHz
5.8 dBi
2.4 GHz
4 dBi
Max. TX Power
6 GHz
26 dBm
5 GHz
26 dBm
2.4 GHz
22 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11ax (WiFi 6/6E)
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11n
6.5 Mbps to 600 Mbps (MCS0 - MCS31 , HT 20/40)
