Hikvision DC Plug Centre Positive Fly Lead Connector Block

Deep learning based human and vehicle targets classification of Motion Detection 2.0

• H.265 Pro+/H.265 Pro/H.265 video compression
• HDTVI/AHD/CVI/CVBS/IP video input
• Audio via coaxial cable
• Up to 10-ch IP camera input (up to 5 MP)
• Encoding ability up to 1080p lite @ 15 fps
• Max. 1200 m for 720p HDTVI signal

High quality imaging with 2 MP, 1920 × 1080 resolution

• 2.8 mm, 3.6 mm fixed lens
• Up to 20 m IR distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS)
• Water and dust resistant (IP67)

Multi-channel SMPS

• 96 W, 12 VDC/1 A max per channel, max total current is 8 A
• Over current/short circuit/over voltage protection
• Good EMC performance
• Compact size; applicable to cameras
• 150 to 285 VAC wide voltage input

BNC Connector Crimp

• The BNC connector is a miniature quick connect/disconnect radio frequency connector used for coaxial cable
• features two bayonet lugs on the female connector
