Display
Viewing Angle 178°(H)/178°(V)
Screen Size 23.8 inch
Active Display Area 527.04 (H) mm × 296.46 (V) mm
Backlight LED
Pixel Pitch 0.2745 (H) mm × 0.2745 (V) mm
Resolution 1920 × 1080
Brightness 300 cd/m²
Color Depth 6 bit
Contrast Ratio 1000:1
Response Time 5 ms
Color Gamut 72% NTSC
Reliability 7 × 24 h
Refresh Rate 75 Hz
Haze Haze 25%, 3H
Interface Video & Audio Input HDMI × 1, VGA × 1
Power
Power Supply 100 to 240 VAC, 50/60 Hz
Power Consumption ≤ 30 W
Standby Consumption ≤ 0.5 W
Working
Environment
Working
Temperature
0 °C to 40 °C (32 °F to 104 °F)
Working Humidity 10% to 85% RH (without condensation)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 5% to 95% RH (without condensation)
General
Casing Material Plastic
VESA 100 mm × 100 mm, M4 × 12
Product Dimensions
(W × H × D)
With base: 540 (W) mm × 418 (H) mm × 220 (D) mm (21.260'' × 16.457'' × 8.661'')
Without base: 540 (W) mm × 324 (H) mm × 46 (D) mm (21.260'' × 12.756'' × 1.811'')
Package Dimensions
(W × H × D)
618 (W) mm × 491 (H) mm × 112 (D) mm (24.331'' × 19.331'' × 4.409'')
Net Weight 3.43 kg
Gross Weight 4.44 kg
Packing List Power cord × 1, Certificate × 1, Warranty Card × 1, VGA Cable × 1
Remarks
*The base is included by default.
*The product appearance and parameters in this specification may vary from your
actual device. Please consult our local sales staff for further information.
Bezel Width Top: 2 mm, bottom: 20 mm, left: 2 mm, right: 2 mm
