Camera
Image Sensor
[Bullet channel]: 1/2.5" Progressive Scan CMOS; [PTZ channel]: 1/2.8" progressive scan
CMOS
Max. Resolution [Bullet channel] 3632 × 1632, [PTZ channel] 2560 × 1440
Min. Illumination
[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;
[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0
Lux with IR
Shutter Speed 1 s to 1/30,000 s
Slow Shutter yes
Day & Night ICR
Zoom [PTZ channel] 25 × optical, 16 × digital
White Balance auto,ATW,sodium lamp,fluorescent lamp,indoor,outdoor,MWB,Locked WB
Lens
Focal Length [Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical
Zoom Speed [PTZ channel]: approx. 3.6 s
FOV
[Bullet channel]: Horizontal field of view: 180±10°, Vertical field of view: 80±5°;
[PTZ channel]:
Horizontal field of view: 55° to 2.4° (wide-tele),
Vertical field of view: 33° to 1.4° (wide-tele),
Diagonal field of view: 61.5° to 2.8° (wide-tele)
Focus semi-auto,manual,auto
Aperture [Bullet channel]: F1.0; [PTZ channel]: F1.6
Illuminator
Supplement Light Type [PTZ channel]: IR; [Bullet channel]: White Light
Smart Supplement Light Yes
Supplement Light Range [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m
PTZ
Movement Range (Pan) 360°
Movement Range (Tilt) -15° to 90° (auto flip)
Pan Speed pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s
Tilt Speed tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
Proportional Zoom yes
Presets 300
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans
Power-off Memory yes
Park Action
preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama
scan
3D Positioning yes
PTZ Status Display yes
Preset Freezing yes
Scheduled Task
preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama
scan,dome reboot,dome adjust,aux output
Exception Detection
IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal
Restart
Video
Region of Interest (ROI) 8 fixed regions for each stream
Main Stream
[Bullet channel]
50 Hz: 25 fps(3632 × 1632, 3680 × 1656)
60 Hz: 30 fps(3632 × 1632, 3680 × 1656)
[PTZ channel]
50 Hz: 25 fps(2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps(2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
[Bullet channel]
50 Hz: 25 fps(1200 × 536, 960 × 432)
60 Hz: 30 fps(1200 × 536, 960 × 432)
[PTZ channel]
50 Hz: 25 fps(704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps(704 × 480, 640 × 480, 352 × 240)
Third Stream
[Bullet channel]
No
[PTZ channel]
50 Hz: 25 fps(1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps(1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression H.265,H.264,MJPEG
Video Bit Rate 32 kbps to 16384 kbps
H.264 Type baseline profile,main profile,high profile
H.265 Type main profile
H.264+ yes
H.265+ yes
SVC yes
