Camera
Image Sensor 1/1.8" Progressive Scan CMOS
Max. Resolution 8160 × 3616
Min. Illumination
Color: 0.009 Lux @ (F1.2, AGC ON), 0.012 Lux @ (F1.4, AGC ON)
B/W: 0.0009 Lux @ (F1.2, AGC ON), 0.0012 Lux @ (F1.4, AGC ON), 0 Lux with IR
Shutter Time 1/25 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 355°, tilt: 0° to 90°
Lens
Lens Type Fixed focal lens, 2.8 mm, four lenses
Focal Length & FOV
2.8 mm,
Single lens image: horizontal FOV 102°, vertical FOV 55°, diagonal FOV 120°,
Panorama Image: horizontal FOV 180°, vertical FOV 95°
Lens Mount M12
Aperture F1.4
DORI
DORI 2.8mm：D: 91.4m, O: 36.3m, R: 18.3m, I: 9.1m
Illuminator
Supplement Light Type IR, four IR LEDs
Supplement Light Range Up to 20 m
IR Wavelength 850 nm
Video
Main Stream
Panorama mode:
50 Hz: 25 fps (8160 × 3616, 8160 × 2304)
60 Hz: 24 fps (8160 × 3616, 8160 × 2304)
Original mode:
50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
Panorama + ePTZ mode:
Panorama channel:
50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
