Camera
Image Sensor 1/2.8" Progressive Scan CMOS
Max. Resolution 1920 × 1080
Min. Illumination Color: 0.002 Lux @ (F1.2, AGC ON)
Shutter Time 1/3 s to 1/100,000 s
Lens
Focal Length & FOV
2.8 mm: horizontal FOV: 107.8°, vertical FOV: 57.9°, diagonal FOV: 126.7°
4 mm: horizontal FOV: 82.8°, vertical FOV: 45.1°, diagonal FOV: 98°
Lens Mount M12
Iris Type Fixed
Aperture
2.8 mm: F2.0
4 mm: F2.0
DORI
DORI
2.8 mm: D: 42.8 m, O: 17 m, R: 8.6 m, I: 4.3 m
4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m
Video
Main Stream
50 Hz: 50 fps (1920 × 1080, 1280 × 720)
60 Hz: 60 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240)
60 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240)
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Bit Rate Control CVR/BVR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) Support 1 fixed region for main stream
Audio
Audio Type Mono
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC
Audio Bit Rate
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64
Kbps (AAC)
Audio Sampling Rate 8 kHz/16 kHz/32 kHz
Environment Noise Filtering Yes
