Video and Audio
IP Video Input
8-ch
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
160 Mbps
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60
HDMI Output
Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output
1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode
HDMI/VGA independent output
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1kΩ, using the audio input)
Decoding
Decoding Format
H.265/H.265+/H.264/H.264+
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback
8-ch
Decoding Capability
2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726
Network
Remote Connection
128-ch
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
Network Protocol
UPnP™, HTTP, HTTPS
Network Interface
Auxiliary Interface
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
SATA
2 SATA interfaces
Capacity
Up to 10 TB capacity for each HDD
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Alarm In/Out
4/1
General
Power Supply
12 VDC, 3.33A
Consumption
≤ 15 W (without HDD)
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10% to 90%
Dimension (W × D × H)
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight
≤ 1 kg (without HDD, 2.2 lb.)
