Camera
Sensor
Resolution
1/2.7" Progressive Scan CMOS
5MP
Min. Illumination
Slow Shutter
120 dB
Color: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
No
Wide Dynamic Range
Day ＆ Night
IR cut filter
Angle Adjustment
Power-off Memory
Tilt: -25° to +55°
Yes
P/N
Protection Level
Lens
P/N
IP68(IEC 60529-2013), IP69K (ISO 20653: 2013), IK10 (IEC 62262: 2002)
Focal Length ＆ FOV
8 mm/12mm/16mm fixed lens
8mm: Horizontal FOV 37°, vertical FOV 28°, diagonal FOV 46°
12mm: Horizontal FOV 28°, vertical FOV 10°, diagonal FOV 30°
16mm: Horizontal FOV 17°, vertical FOV 13°, diagonal FOV 22°
Lens Mount
Aperture
Illuminator
M12
F1.6
IR Wavelength
IR Range
Video
650 nm + 730 nm
Up to 30 m IR range
Max. Resolution
Main Stream
2560 × 1920
50 Hz: 25 fps (2560 × 1920, 1920 × 1080, 1280 × 720);
60 Hz: 30 fps (2560 × 1920, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480);
60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream
Video Compression
50 Hz: 25 fps (1280 × 720)
Main stream: H.265/H.264/H.265+/H.264+
Sub stream: H.265/H.264/H.265+/H.264+
Third stream: H.265/H.264/H.265+/H.264+
H.264 Type
H.265 Type
BaseLine Profile/Main Profile/High Profile
Main Profile
Bit Rate Control
Video Bit Rate
Constant Bit Rate, Variable Bit Rate
First stream: 512 bps-16384 bps
Second stream: 256 bps-4096 bps
Third stream: 256 bps-4096 bps
Event
Basic Event
Motion detection, video tampering alarm, exception
Smart Functions
Recognition
License Plate Information
License Plate Recognition (Up to 15m)
Plate, No-Plate, Capture Date/Time, Coordinate (GPS), Device Name and Picture
Capture Speed Range
Vehicle Type
Up to 140km/h
Car/Motorcycle/Van/Bus/Truck/Others
