Camera
Image Sensor
2 MP CMOS
Signal System
PAL/NTSC
Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Lens
Lens Type
2.8 mm, 3.6 mm Fixed Lens
Focal Length & FOV
2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°
Lens Mount
M12
Illuminator
Supplement Light Range
Up to 20 m
Supplement Light Type
Smart,IR,White Light
Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC
Wide Dynamic Range (WDR)
Digital WDR
Image Parameters Switch
STD/HIGH-SAT
Day/Night Mode
Auto/Color
White Balance
Auto
Image Enhancement
DWDR, BLC, Global
Noise Reduction
2D DNR
Image Settings
Brightness, Mirror, Smart IR, Sharpness, AGC
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
General
Language
English
Operating Condition
-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Material
Plastic
Communication
HIKVISION-C
Dimension
138.8 mm × 60.9 mm × 57.9 mm (5.465" × 2.389" 2.278")
Weight
Approx. 145 g (0.32 lb.)
Power
12 VDC ± 25%, Max. 3.3 W
Approval
Protection
IP67
