Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
Signal System
PAL/NTSC
Light Alarm
Solid Light Alarm (White Light)
Lens
Lens Type
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Focal Length & FOV
2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115°
3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90°
6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV: 58°
Lens Mount
M12
Illuminator
Supplement Light Type
White Light
Supplement Light Range
Up to 40 m
Smart Supplement Light
Yes
Image Parameters Switch
STD/HIGH-SAT/HIGHLIGHT
Image Settings
Brightness, Mirror, Sharpness, Anti-Banding, AGC
Frame Rate
TVI: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC
Day/Night Mode
Color
Wide Dynamic Range (WDR)
Digital WDR
Image Enhancement
DWDR, BLC, HLC, Global
Noise Reduction
3D DNR/2D DNR
White Balance
Auto/Manual
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
General
Material
Metal
Dimension
194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
Weight
Approx. 516 g (1.14 lb)
Operating Condition
-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Communication
HIKVISION-C
Language
English
Power
12 VDC ± 25%, Max. 4 W
*You are recommended to use one power adapter to supply the power for one camera.
Approval
Protection
IP67
