Camera
Image Sensor 2 MP CMOS
Max. Resolution 1920 (H) × 1080 (V)
Min. Illumination 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50, 000 s
Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
Signal System PAL/NTSC
Lens
Lens Type 2.8 mm, 3.6 mm fixed focal lens
Focal Length & FOV
2.8 mm, horizontal FOV: 105°, vertical FOV: 55°, diagonal FOV: 125°
3.6 mm, horizontal FOV: 84°, vertical FOV: 45°, diagonal FOV: 99°
Lens Mount M12
Illuminator
Supplement Light Type White Light
Supplement Light Range Up to 20 m
Smart Supplement Light Yes
Image Parameters Switch STD/HIGH-SAT/HIGHLIGHT
Image Settings Brightness, Sharpness, Anti-banding, AGC
Frame Rate
TVI: 1080p @25 fps/30 fps
CVI: 1080p @25 fps/30 fps
AHD: 1080p @25 fps/30 fps
CVBS: PAL/NTSC
Day/Night Mode Color
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement DWDR, BLC, HLC, Global
Noise Reduction 3D DNR/2D DNR
White Balance Auto, Manual
Interface
Video Output Switchable TVI/AHD/CVI/CVBS
Alarm Solid Light Alarm (White Light)
General
Material Plastic
Power
12 VDC ± 25%, max. 2 W, *You are recommended to use one power adapter to supply
the power for one camera.
Dimension 161.1 mm × 68.4 mm (6.34" × 2.69")
Weight Approx. 389 g (0.86 lb.)
Operating Condition -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensing)
Communication HIKVISION-C
Language English
Approval
Protection IP67
