1/3" Progressive CMOS, ICR, 2560x1440:20fps(P)/(N), 2304x129

Image Sensor 1/3″ Progressive Scan CMOS
Min. Illumination Colour: 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Day & Night IR Cut Filter
WDR 120 dB
Angle Adjustment Pan: 0° to 355° / tilt: 0° to 75° / rotate: 0° to 355°
Lens
Lens Type Fixed lens, 2.8 / 4 / 6 mm
Aperture F1.6
FOV (Field of View) 2.8 mm: Horizontal FOV: 103°, Vertical FOV: 58°, Diagonal FOV: 123°
4 mm: Horizontal FOV: 83°, Vertical FOV: 45°, Diagonal FOV: 99°
6 mm: Horizontal FOV: 51°, Vertical FOV: 29°, Diagonal FOV: 58°
Lens Mount M12
Illuminator
IR Range Up to 30 m
Wavelength 850 nm
Video
Max. Resolution 2688 × 1520
Main Stream 50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
