Camera
Image Sensor 1/3″ Progressive Scan CMOS
Min. Illumination Color: 0.018 Lux @(F1.6, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Wide Dynamic Range 120 dB
Day & Night ICR Cut
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
Lens
Lens Type & FOV
2.8 mm, horizontal FOV 98°, vertical FOV 53°, diagonal FOV 115°
4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88°
6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57°
Aperture 2.8 mm: F2.0; 4 mm: F2.0; 6 mm: F1.6
Lens Mount M12
Illuminator
IR Range 30 m
Wavelength 850 nm
Smart Supplement Light Yes
Video
Max. Resolution 2560 × 1440
Main Stream
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 1fps (1280 × 720, 640 × 360)
60Hz: 1fps (1280 × 720, 640 × 360)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Stream Type Main stream/Sub-stream/Third stream
Scalable Video Coding (SVC) H.265 and H.264 support
Region of Interest (ROI) 1 fixed region for main stream and sub-stream
* Note: The frame rate of the sub-stream cannot exceed the maximum frame rate of the current main stream.
