Camera
Image Sensor 1/1.8" progressive scan CMOS
Min. Illumination Color: 0.0014Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Speed 1/3s to 1/100,000s
Slow Shutter Yes
Wide Dynamic Range 120dB
Angle Adjustment Pan: 0 to 360°, tilt: 0 to 90°, rotation: 0 to 360°
Lens
Lens Type 2.8/4/6 mm, fixed lens
FOV
2.8 mm, horizontal FOV: 102°, vertical FOV: 51°, diagonal FOV: 125°
4 mm, horizontal FOV: 89°, vertical FOV: 46°, diagonal FOV: 105°
6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62°
Aperture F1.0
Lens Mount M16
Illuminator
White Light Range 30 m
Video
Max. Resolution 2560 × 1440
Main Stream
50Hz: 25fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 24fps (2560 × 1440), 30fps(2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third stream
50Hz: 1fps (1280 × 720, 640 × 480, 640 × 360, 352 × 288, 320 × 240)
60Hz: 1fps (1280 × 720, 640 × 480, 640 × 360, 352 × 288, 320 × 240)
Video Compression
Main stream: H.265+/H.264+/H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Video Bit Rate 32 Kbps to 8 Mbps
H.264 Type Baseline Profile, Main Profile, High Profile
H.265 Type Main Profile
Stream Type Main stream/Sub-stream/third stream
Simultaneous Live View Up to 6 channels
Scalable Video Coding (SVC) Yes
Region of Interest (ROI) 1 fixed region for each stream
* Note: The frame rate of the sub-stream cannot exceed the maximum frame rate of the current main stream.
Network
API ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP,
IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, watermark, IP address
filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication
for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS
1.2
Network Storage microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
Client iVMS-4200, Hik-Connect, Hik-Central
Web Browser IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11
