Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Resolution 1280 × 1024
Pixel Pitch 12 μm
Spectral Range 8 μm to 14 μm
NETD ≤ 35 mK (@ 25°C,F# = 1.0)
Focal Length 30 to 300 mm
Focus Mode Semi-auto & Manual
IFOV 0.4 to 0.04 mrad
Aperture F0.85 to F1.35
Field of View 28.7° × 23.2° (H × V) to 2.9° × 2.4° (H × V)
Min. Focusing Distance 3 m
Digital Zoom × 2, × 4, × 8
Optical Module
Image Sensor 1/1.8" Progressive Scan CMOS
Resolution 1920 × 1080, 2 MP
Min. Illumination Color: 0.005 Lux @ (F3.5, AGC ON), B/W: 0.0005 Lux @ (F3.5, AGC ON)
Field of View 31.2° × 17.8° (H × V) to 0.41° × 0.23° (H × V)
Focal Length 10 to 1000 mm, 100x
Aperture (Range) F3.0 to F11.5
Focus Mode Semi-auto & Manual
Digital Zoom × 2, × 4, × 8, × 16
Shutter Speed 1 s to 1/30,000 s
WDR 120 dB
Optical Defog Yes
Image Effect
Picture in Picture Display partial image of thermal channel on the full screen of optical channel
Target Coloration Supported in white hot and black hot mode
Image Stabilization
Thermal channel: Built-in gyroscope to improve EIS performance(conflicted with
intelligent function); Optical channel: Optical Image Stabilization (OIS)
