Thermal Module
Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Resolution 640 × 512
Pixel Pitch 17 μm
Spectral Range 8 μm to 14 μm
NETD ≤ 35 mK (@25°C, F# = 1.0)
Focal Length 25 mm
Focus Mode Semi-auto & Manual
IFOV 0.68 mrad
Aperture F1.0
Field of View 24.9° × 20° (H × V)
Min. Focusing Distance 1.5 m
Digital Zoom ×2, ×4, ×8
Optical Module
Image Sensor 1/1.8'' Progressive Scan CMOS
Resolution 2688 × 1520, 4 MP
Min. Illumination Color: 0.005 Lux @ (F1.3, AGC ON), B/W: 0.001 Lux @ (F1.3, AGC ON)
Field of View 56.6° × 33.7° (H × V) to 1.8° × 1.0° (H × V)
Focal Length 6 to 240 mm, 40x
Aperture (Range) F1.3 to F4.6
Focus Mode Semi-auto, manual
Digital Zoom ×2, ×4, ×8, ×16
Shutter Speed 1 s to 1/100,000 s
Day & Night Mode IR Cut Filter
WDR 120 dB
Optical Defog Yes
Image Effect
Picture in Picture Display partial image of thermal channel on the full screen of optical channel
Target Coloration Yes. Supported in white hot and black hot mode.
PTZ
Movement Range Pan: 360° Continuous Rotate; Tilt: From -90° to + 90° (auto flip)
Pan Speed Configurable, From 0.01°/s to 40°/s
Tilt Speed Configurable, From 0.01°/s to 40°/s
Proportional Zoom Yes
Presets 300
Patrol Scan 8; Up to 32 presets per patrol
Pattern Scan 4; More Than 10 Minutes Per Pattern
Power Off Memory Yes
Park Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PT Status Turn On/Turn Off
Scheduled Task
Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama
Scan/Dome Reboot/Dome Adjust/Aux Output
Illuminator
IR Distance Up to 200 m
IR Intensity and Angle Automatically adjusted
